AXEON

211707- MEMBRANE, ENCAPSULATED, 1/4" QC, NE, 1812, 100 GPD, AXEON

Part #: 211707
Login / Register
Description

The AXEON NE-1812 Encapsulated Reverse Osmosis Membrane is designed for residential and point-of-use RO systems requiring higher daily water production with simplified, leak-free installation. Rated at 100 gallons per day, this encapsulated membrane is ideal for under-sink drinking water systems and compact RO units serving increased household or specialty demand.

The all-in-one sealed housing integrates the RO membrane with 1/4″ quick-connect fittings, eliminating the need for a separate membrane housing and reducing installation time. Manufactured using thin-film composite (TFC) membrane technology, the NE-1812 delivers consistent dissolved solids reduction and dependable permeate flow.

(Recommended Flow Restrictor: AXEON Capillary Flow Restrictor Blue 300 ML/Min 100 GPD - 211951)



Features:

  • 100 GPD encapsulated reverse osmosis membrane
  • Integrated sealed housing design
  • 1/4″ quick-connect inlet and outlet connections
  • Thin-film composite (TFC) membrane technology
  • Simplified installation and replacement
  • Leak-resistant, space-saving construction
  • Designed for residential and point-of-use RO systems

Description: NE-2012-100E

Applied Pressure (psi / bar): 60 / 4.14

Permeate Flow Rate (gpd / lpm): 100 / 15.77

Nominal Salt Rejection %: 96

Connection Size (in): 1/4" QC

Membrane Type: Polyamide Thin-Film Composite

Maximum Operating Temperature (°F / °C): 100 / 37.80

Maximum Operating Pressure (psi / bar): 125 / 8.62

Maximum Feed Flow Rate (gpm / lpm): 2 / 7.60

pH Range, Continuous Operaiton: 3 - 11

Maximum Feed Silt Density Index (SDI): 5

Chlorine / Chloramine Tolerance (ppm): 0
