AXEON

211692- MEMBRANE, SE1, 8040, DRY, AXEON

Name: 211692- MEMBRANE, SE1, 8040, DRY, AXEON
Brand: AXEON
SKU: 211692
Price: 2653.6 USD
Availability: InStock

Part #: 211692

Product variants

Login / Register

Description

The AXEON SE1-8040 Reverse Osmosis Membrane is designed for dependable, general-purpose water purification in high-capacity commercial and industrial reverse osmosis applications. Manufactured using advanced thin-film composite (TFC) membrane technology, this element delivers consistent dissolved solids reduction with stable permeate flow and reliable system performance.

Supplied in a dry-shipped configuration, the SE1-8040 offers extended shelf life and simplified storage prior to installation. Its industry-standard 8.0″ × 40″ size makes it compatible with a wide range of industrial RO systems and OEM equipment requiring cost-effective, dependable RO performance at higher production rates.

Features:

Reverse osmosis membrane for general-purpose applications
Dry-shipped for extended shelf life
Advanced thin-film composite (TFC) technology
Consistent permeate quality and performance
Standard 8.0″ × 40″ membrane size
Designed for commercial and industrial RO systems
AXEON-engineered reliability

Literature

Specification Sheet

specifications

Description: SE1-8040

Applied Pressure (psi / bar): 800 / 55.16

Permeate Flow Rate (gpd / m³/d): 7500 / 6.81

Nominal Salt Rejection %: 99.75

Membrane Type: Polyamide Thin-Film Composite

Maximum Operating Temperature (°F / °C): 113 / 45

Maximum Operating Pressure (psi / bar): 1200 / 82.70

pH Range, Continuous Operaiton: 2 - 11

pH Range, Short Term Cleaning (30 Min.): 1 - 13

Maximum Feed Silt Density Index (SDI): 5

Chlorine / Chloramine Tolerance (ppm): 0

Maximum Feed Flow Rate (gpm): 75

Compatible with:

AXEON:	SW1-8040
Filmtec:	SW30HRLE-400
Hydranautics:	SWC4B-MAX
Suez:	AD-400, 34
Toray:	TM820E-400, TM820M-400
LG:	LG SW 400 GR
