AXEON N-2000 RO System with black frame, digital control panel, three vertical filter columns, and pressure gauges for industrial-scale water purification

AXEON

210309- SYSTEM, RO, N-2000, 220V 60HZ 1PH, AXEON

Name: 210309- SYSTEM, RO, N-2000, 220V 60HZ 1PH, AXEON
Brand: AXEON
SKU: 210309
Price: 10525.78 USD
Availability: InStock

Part #: 210309

Product variants

Login / Register

Description

The AXEON® N-Series Reverse Osmosis Systems are engineered for commercial and light industrial applications requiring high-quality water production with dependable performance. Each system is factory tested and delivered ready for installation, featuring a compact, pre-plumbed, and pre-wired design for quick setup and reliable operation.

The N-Series is available in capacities ranging from 2,000 to 16,000 gallons per day, making it ideal for restaurants, laboratories, hydroponic operations, car washes, and other commercial water treatment needs. Designed and manufactured in the U.S.A., the AXEON® N-Series provides a cost-effective, high-performance solution for tap water purification.

Features:

Compact, pre-assembled, and pre-wired design
Stainless steel multi-stage booster pump
AXEON® FRP membrane housings
AXEON® 4" × 40" membrane elements
5-micron sediment pre-filter
Powder-coated steel frame for corrosion resistance
LCD controller with TDS, temperature, and status monitoring
Nominal 98.5 % salt rejection
High recovery rates up to 65 %
Designed and built in the U.S.A.

safety certification

NSF-61 Certified Membrane

Literature

videos

specifications

Specifications:

Model: N-2000
AXEON Part Number: 210309

Design:

Configuration: Single Pass
Feedwater Source: TDS < 2,000 ppm
Standard Recovery Rate %: 32

Flow Rates:

Permeate Flow (gpd / lpd): 2,000 / 7,570
Permeate Flow (gpm / lpm): 1.39 / 5.26
Minimum Concentrate Flow (gpm / lpm): 3 / 11.36
Concentrate Recycle Flow (gpm / lpm): Up to 2 / 7.57

Connections:

Feed (in): 1 FNPT
Permeate (in): 1/2 FNPT
Concentrate (in): 1/2 FNPT

Membranes:

Membrane(s) Per Vessel: 1
Membrane Quantity: 1
Membrane Size: 4040
Nominal TDS Rejection %: 98.5

Vessels:

Vessel Array: 1
Vessel Quantity: 1

Pumps:

Pump Type: Multi-Stage
Motor HP: 1.5
RPM @ 60Hz: 3480

System Electrical:

Standard Voltage + Amp Draw: 220V, 60Hz, 1PH, 8.5A

Operating Limits:

Maximum Feed Temperature (°F / °C): 85 / 29
Minimum Feed Temperature (°F / °C): 40 / 4
Maximum Ambient Temperature (°F / °C): 120 / 49
Minimum Ambient Temperature (°F / °C): 40 / 4
Maximum Feed Pressure (psi / bar): 85 / 6
Minimum Feed Pressure (psi / bar): 45 / 3
Maximum Operating Pressure (psi / bar): 200 / 14
Maximum Feed Silt Density Index (SDI): < 3
Maximum Turbidity (NTU): 1
Maximum Free Chlorine (ppm): 0
Maximum TDS (ppm): Up to 2,000
Maximum Hardness (gpg): 0
Maximum pH (Continuous): 11
Minimum pH (Continuous): 2
Maximum pH (Cleaning 30 Minutes): 13
Minimum pH (Cleaning 30 Minutes): 1

Warranty:

1-Year Warranty
