SYSTEM, RO, LC-750, AXEON
Couldn't load pickup availability
The AXEON LC-750 Reverse Osmosis System is designed for light commercial water treatment applications requiring dependable mid-range production with consistent water quality. With a nominal output of 750 gallons per day, this system is well suited for food service, laboratories, hydroponics, ice machines, and other commercial point-of-use installations.
The LC-750 features a multi-stage filtration process that includes sediment and carbon pre-filtration to protect the RO membrane, followed by a high-rejection reverse osmosis membrane for effective dissolved solids reduction. Its compact, service-friendly design allows for easy installation and maintenance while delivering reliable long-term performance.
Features:
- 750 GPD nominal production capacity
- Multi-stage reverse osmosis filtration
- Sediment and carbon pre-filtration
- High-rejection RO membrane Compact, space-efficient design
- Reliable and consistent performance
- Easy installation and maintenance
- Ideal for light commercial applications
Model: LC-750
Capacity (gpd): 750
Configuration: Single Pass
Feedwater Source: TDS < 1,000 ppm
Standard Recovery Rate %: Up to 75
Permeate Flow (gpm): 0.52
Minimum Feed Flow (gpm): 2.22
Maximum Feed Flow (gpm): Up to 8
Feed (in): 1/2" QC
Permeate (in): 3/8" QC
Concentrate (in): 3/8" QC
Membrane(s) Per Vessel: 1
Membrane Quantity: 1
Membrane Size: 3018
Nominal Salt Rejection %: 98
Vessel Array: 1
Vessel Quantity: 1
Pump Type: Rotary Vane 401 Low Lead Brass
Motor HP: 1/3
RPM @ 60Hz: 1725
Standard Voltage + Amp Draw: 110V, 1 PH, 50 / 60Hz, 6.6A
Warranty: 1-Year
Q&A
Have a Question?
Be the first to ask a question about this.
NEED HELP?
Need help finding a replacement part? Fill out our part request form and someone will get back to you shortly. Can’t wait? You can also call our customer support line.
Replacement Parts
- Part #: 200626
- Brand : AXEON
200626- CARTRIDGE, DEPTH FILTER, POLYPRO, 2.5" X 20", MIC 5, AXEON
Login / Register
- Part #: 200659
- Brand : AXEON
200659- CARTRIDGE, BLOCK, CARBON, 2.5" x 20", 10 MIC, CBF-25-2010, AXEON
Login / Register
- Part #: 207295
- Brand : PENTAIR WATER
207295- HOUSING, FILTER, WHT/WHT, 2.5" X 20", SGL O-RING, NPR, 3/8" FNPT, SFH25, PENTAIR
Login / Register
- Part #: 200808
- Brand : NIDEC
200808- MOTOR, CARBONATOR, 1/3 HP, 110/220V 50/60HZ, 48Y, NIDEC
Login / Register
- Part #: 211447
- Brand : AXEON
211447- METER, FLOW, PM, 0.2-2 GPM, 1/2"MNPT X 1/4"FNPT, AXEON
Login / Register
- Part #: 205104
- Brand : AXEON
205104- METER, FLOW, PM, 1-5 GPM, SS VALVE, 1/2" MNPT X 1/2" MNPT, AXEON
Login / Register
- Part #: 204165
- Brand : AXEON
204165- GAUGE, PM, GLY FILL, 0-100 PSI/BAR, 2.5" DIA, 1/4", AXEON
Login / Register
- Part #: 203385
- Brand : HM Digital
203385- METER, TDS, INLINE, DM-2, 1/2"QC, HM DIGITAL
Login / Register
- Part #: 200904
- Brand : AXEON
200904- GAUGE, PM, GLY FILL, 0-300 PSI/BAR, 2.5" DIA, 1/4", AXEON
Login / Register
- Part #: 209246
- Brand : AXEON
209246- METER, FLOW, PM, 85 GPH, SS 304 VALVE, 1/4" MNPT X 1/4" MNPT
Login / Register
- Part #: 205099
- Brand : AXEON
205099- GAUGE, PM, GLY FILL, 0-100 PSI/BAR, 2.5" DIA, SS, AXEON
Login / Register
- Part #: 207663
- Brand : FLUID-O-TECH
207663- PUMP, VANE, LOW LEAD BRASS, BYPASS, 2.3 GPM, 401, FLUID-O-TECH
