208419- HOUSING, MEMBRANE, FRP-4040-300E, 1/2" P X 3/4" C FNPT, AXEON
Couldn't load pickup availability
The AXEON 4040 FRP Membrane Housing is designed to securely contain standard 4.0″ × 40″ reverse osmosis membrane elements in commercial and light industrial RO systems. Constructed from durable fiberglass reinforced plastic (FRP), this housing provides reliable pressure containment up to 300 PSI, ensuring safe and consistent system operation.
Featuring 1/2″ FNPT permeate and 3/4″ FNPT concentrate connections, this housing allows for straightforward system integration and dependable sealing. Its rugged construction and corrosion-resistant materials make it well suited for demanding water treatment environments requiring long service life and stable performance.
Features:
- Fiberglass Construction
- End Entry Connections
- Single Piece ABS End Plugs
- True–Lock™ Integrated Locking System
- Accommodates All Standard Sized Membrane Elements
- Interconnector and Mounting Clamps Available
- Includes Mounting Strap and Rubber Saddles
Model Number: FRP-4040-300E
Number of Membranes: 1
Membrane Diameter (inch / mm): 4 / 101.60
Membrane Length (inch / mm): 40 / 1016
Feed Connection (inch): 3/4" FNPT
Permeate Connection (inch): 1/2" FNPT
Concentrate Connection (inch): 3/4" FNPT
AXEON Part Number: 208419
Maximum Operating Pressure (psi / bar): 300 / 21
Minimum Operating Temperature (F° / C°): 35 / 2
Maximum Operating Temperature (F° / C°): 150 / 66
