207153- CONNECTOR, MALE, 1/2" QC X 1/2" MNPT, PARKER
Couldn't load pickup availability
The Parker Male Connector is a high-quality, tool-free push-to-connect fitting designed for efficient and secure joining of tubing to a ½″ male NPT port. Ideal for water filtration, beverage systems, and industrial fluid routing applications, this fitting offers reliable performance in a compact, easy-install design.
Features:
- ½″ push-to-connect quick-connect port for fast tool-free tubing insertion
- ½″ male NPT (MNPT) thread for secure pipe or port connection
- 90° elbow or straight shape variant (depending on model) for tight-space installations
- Acetal body material ensures durability and chemical resistance
- EPDM O-ring seal for reliable leak-free service
- Rated for use with air, water, soft drinks, beer, wine, dyes and general fluid systems
- Compact design simplifies installation in tight spaces
Connection 2 Style: Male Pipe
Body Material: Acetal
Connection 1 Tube O.D. (inch): 1/2
Connection 2 Tube O.D. (inch): na
Connection 2 Thread Size (inch): 1/2
Connection 1 Style: Push-to-Connect
Shape: Connector
Style: Tube to Pipe
Minimum Operating Temperature: -20 °F, -29 °C
Maximum Operating Temperature: 180 °F, 85 °C
Maximum Operating Pressure: 300 psi, 20 bar
Tube Material:Polyethylene, Polypropylene, Nylon, Vinyl, Fluoropolymer, Polyurethane
Media: Air, Water, Soft Drinks, Beer, Wine, Dyes
Application: Filtration, Food Process, Dispensing, Medical, Water Purification
O-Ring Material: EPDM
Specifications Met: FDA, NSF-51, NSF-61
