200403- MEMBRANE, NF3, 2540, DRY, AXEON

Part #: 200403
Login / Register

The AXEON NF3-2540 Nanofiltration Membrane is designed for selective separation in residential, commercial, and light industrial water treatment applications requiring partial salt rejection with lower operating pressure than reverse osmosis. Built with advanced thin-film composite (TFC) nanofiltration technology, this membrane effectively reduces hardness, color, and organic compounds while allowing partial passage of monovalent salts to help maintain balanced water chemistry.

Supplied in a dry-shipped configuration, the NF3-2540 offers extended shelf life and simplified storage prior to installation. Its standard 2.5″ × 40″ size makes it compatible with a wide range of commercial NF systems and OEM equipment requiring efficient nanofiltration performance.



Features:

  • Nanofiltration membrane for selective ion removal
  • Dry-shipped for extended shelf life
  • Advanced thin-film composite (TFC) NF technology
  • Reduces hardness, color, and organic compounds
  • Allows partial passage of monovalent salts
  • Standard 2.5″ × 40″ membrane size
  • Designed for residential, commercial, and light industrial applications

Description: NF3-2540

Applied Pressure (psi / bar): 70 / 4.83

Permeate Flow Rate (gpd / m³/d): 850 / 3.22

Nominal Salt Rejection %: 40 - 50

Membrane Type: Polyamide Thin-Film Composite

Maximum Operating Temperature (°F / °C): 113 / 45

Maximum Operating Pressure (psi / bar): 600 / 41

pH Range, Continuous Operaiton: 2 - 11

pH Range, Short Term Cleaning (30 Min.): 1 - 12

Maximum Feed Silt Density Index (SDI): 5

Chlorine / Chloramine Tolerance (ppm): 0

Maximum Feed Flow Rate (gpm): 6
