200368- MEMBRANE, HR3, 2514, DRY, AXEON
Couldn't load pickup availability
The AXEON HR3-2514 Reverse Osmosis Membrane is engineered for high-rejection performance in residential and light commercial reverse osmosis applications. Designed using advanced thin-film composite (TFC) membrane technology, this element provides excellent dissolved solids reduction while maintaining stable permeate flow and consistent system efficiency.
Supplied in a dry-shipped configuration, the HR3-2514 offers extended shelf life and simplified storage prior to installation. Its compact 2.5″ × 14″ size makes it ideal for small RO systems, point-of-use installations, and OEM equipment requiring reliable, high-quality water purification.
Features:
- High-rejection reverse osmosis membrane
- Dry-shipped for extended shelf life
- Advanced thin-film composite (TFC) technology
- Consistent permeate quality and performance
- Compact 2.5″ × 14″ membrane size
- Designed for residential and light commercial RO systems
- AXEON-engineered reliability and quality
Description: HR3-2514
Applied Pressure (psi / bar): 225 / 15.51
Permeate Flow Rate (gpd / m³/d): 150 / 0.57
Nominal Salt Rejection %: 99.5
Membrane Type: Polyamide Thin-Film Composite
Maximum Operating Temperature (°F / °C): 113 / 45
Maximum Operating Pressure (psi / bar): 600 / 41
pH Range, Continuous Operaiton: 2 - 11
pH Range, Short Term Cleaning (30 Min.): 1 - 13
Maximum Feed Silt Density Index (SDI): 5
Chlorine / Chloramine Tolerance (ppm): 0
Maximum Feed Flow Rate (gpm): 6
