FilmTec membranes offer reliable performance with a 99.7% salt rejection rate and can operate at pressures up to 1,000 psi. They come in over 25 configurations, including SW30, BW30, and NF series, designed for industrial water treatment.
Water treatment experts require membrane elements with verified specifications and reliable performance data. DuPont FilmTec membranes provide documented operational parameters including precise flow rates, rejection percentages, and pressure tolerances that enable accurate system design and predictable outcomes. Industrial operators select FilmTec membranes based on 3 critical performance factors: polyamide thin-film composite construction, automated precision fabrication processes, and consistent temperature ranges up to 113°F (45°C).
FilmTec membrane technology operates across pH ranges from 2-11 for continuous operation and 1-13 for cleaning cycles. These specifications support municipal water treatment facilities processing over 10 gpm (2,300 L/h) of permeate and seawater desalination plants requiring maximum operating pressures. The SW30 series handles seawater applications with flow rates optimized for both sea-based and land-based desalinators, while BW30 series membranes reduce operating pressures by 33% for brackish water treatment systems.
How Do DuPont FilmTec Membrane Technologies Deliver Superior Performance?
DuPont FilmTec membranes achieve superior performance through polyamide thin-film composite construction, automated precision fabrication, and testing at maximum operating pressures of 1,000 psi for seawater and 600 psi for brackish water applications.
FilmTec membrane construction utilizes polyamide thin-film composite technology with automated fabrication processes that ensure precision and consistency across 4 performance categories:
- Operating temperature range: 113°F (45°C) maximum across all series including SW30, BW30, and NF configurations
- pH tolerance: Continuous operation 2-11, cleaning cycles 1-13 for chemical compatibility
- Pressure capabilities: SW30 series 1,000 psi (69 bar), BW30 series 600 psi (41 bar) maximum operating pressure
- SDI tolerance: Maximum 5 for consistent feed water quality requirements
The SW30 series handles seawater desalination with flow rates optimized for both sea-based and land-based operations. These membranes maintain excellent salt rejection while providing the highest productivity available in the market. BW30 series delivers 33% lower pressure requirements for brackish water treatment, reducing pump size, operational costs, and energy consumption.
Dupont FilmTec membrane elements undergo automated precision element fabrication that results in consistent product performance. The manufacturing process combines improved seawater membrane technology with quality control systems that enable predictable system design parameters. Industrial operators select FilmTec membranes based on documented flow rates, rejection percentages, and operational tolerances that support large-scale municipal and industrial water treatment systems processing over 10 gpm (2,300 L/h) of permeate.
What Are the Key DuPont FilmTec Membrane Series Available?
Water treatment professionals utilize 5 primary FilmTec series: SW30 for seawater, BW30 for brackish water, NF90/NF270 for nanofiltration, ECO series for energy efficiency, and XLE for low-energy applications.
| Series | Application | Max Pressure | Key Feature |
|---|---|---|---|
| SW30 | Seawater | 1,000 psi | Highest flow rates |
| BW30 | Brackish water | 600 psi | 33% lower pressure |
| NF90/NF270 | Nanofiltration | 600 psi | Selective contaminant removal |
| ECO | Energy efficiency | 600 psi | High salt rejection, low pressure |
| XLE | Low energy | 600 psi | Cold water productivity |
Each FilmTec series targets specific water treatment challenges. SW30 elements operate at maximum 1,000 psi with excellent salt rejection for desalination applications including sea-based and land-based facilities. BW30 series delivers salt separation for brackish water at 600 psi maximum pressure with 33% lower pressure requirements. NF90 and NF270 provide selective removal of divalent ions and organic compounds while maintaining high permeability for utility applications. ECO series membranes combine high salt rejection with low pressure operation for enhanced fouling protection. XLE membranes produce water quality at very low applied pressure, especially effective in cold water conditions.
Why Do Industrial Water Treatment Systems Specify FilmTec Membranes?
Industrial water treatment systems specify FilmTec membranes because they provide documented reliability with consistent 99.7% salt rejection, proven durability through automated precision manufacturing, and technical support from 36 years of membrane technology expertise.
Industrial advantages include:
- Consistency: Automated fabrication ensures identical performance across membrane batches
- Durability: Wide pH cleaning range (1-13) enables effective fouling management
- Support: Technical assistance for system optimization and troubleshooting
FilmTec membranes serve large-scale industrial and municipal water treatment systems producing greater than 10 gpm (2,300 L/h) of permeate. The BW30HRLE series offers salt rejection with 33% lower pressures, reducing pump size requirements and operational expenses for industrial installations.
How Do FilmTec Membrane Installation and Maintenance Requirements Compare?
FilmTec membrane installation requires standard pressure vessel compatibility with 8-inch diameter housings, while maintenance involves chemical cleaning cycles using pH 1-13 range solutions and monitoring of SDI levels below 5.0.
Installation specifications:
- Housing compatibility: Standard 8-inch pressure vessels
- Configuration options: 4040, 4021, 2540, 2521 element sizes
- Flow direction: Cross-flow operation with concentrate and permeate streams
- Mounting: Horizontal installation with proper support
Maintenance protocols: Regular FilmTec membrane maintenance includes monitoring differential pressure across elements, maintaining feed water SDI below 5.0, and implementing cleaning cycles when flux decline reaches 10-15%. Chemical cleaning uses alkaline and acidic solutions within pH 1-13 range for effective fouling removal.
What Water Treatment Applications Benefit Most from FilmTec Membranes?
FilmTec membranes excel in seawater desalination, brackish water treatment, and industrial process water applications requiring consistent quality with flow rates from 2,300 L/h to maximum system capacity configurations.
Primary applications include:
- Seawater desalination: SW30 series for municipal and industrial freshwater production
- Brackish water treatment: BW30 series for groundwater and surface water purification
- Industrial process water: NF series for selective contaminant removal
- Food and beverage: Low fouling membranes for sanitary applications
- Power generation: High-purity water for boiler feed applications
Performance optimization varies by configuration: Different FilmTec configurations optimize specific treatment objectives. The SEAMAXX series maximizes production capacity for high-salinity applications, while ECO series provides energy-efficient operation for cost-sensitive installations. NF270 and NF90 membranes target organic compound removal including THM precursors and PFAS while maintaining beneficial mineral content for drinking water applications.
Where Can Water Treatment Professionals Source FilmTec Membranes?
Water treatment professionals source authentic FilmTec membranes through authorized distributors like AXEON Supply, which maintains inventory of 25+ FilmTec configurations with technical specifications and compatibility verification.
Supply chain advantages include:
- Inventory availability: Stock maintained for immediate shipment
- Technical verification: Specifications confirmed for system compatibility
- Documentation: Complete operating parameters and installation guidelines
- Support access: Technical assistance for membrane selection and optimization
Procurement considerations: Professional water treatment installations require verified FilmTec membrane authenticity with complete documentation. AXEON Supply provides technical specifications, operating parameters, and compatibility verification for proper system integration and performance optimization across SW30, BW30, NF90, and ECO series configurations.
Why Water Treatment Experts Trust DuPont FilmTec Membranes
Water treatment experts trust DuPont FilmTec membranes for consistent performance and documented reliability in industrial and municipal applications. With 25+ configurations, precise operating specifications, and proven durability, DuPont FilmTec membranes provide the technical foundation for effective water treatment system design across diverse applications from seawater desalination to industrial process water purification. AXEON Supply ensures professionals access authentic FilmTec membranes with complete technical documentation and compatibility verification for optimal system integration.
